10,000 lb Symmetrical 2-Post Lift with Thread-Up Adapters

Item Number: ROTSPO10RA - Supplier: ROTARY LIFT

Description

For decades, Rotary® has been the recognized leader in vehicle service lifts. This legendary reputation has set the standard for quality, durability, reliability and attention to safety throughout the automotive service market. With Rotary lifts, you have the service and support you need. Our world-wide network of service companies are always standing by.

Most of our lifts are third party tested by ETL and certified by ALI to meet or exceed strict ANSI standards such as cable cut and deformation tests. Be sure the lift you buy has the gold ALI/ETL label that assures your lift has been tested to meet these standards.

Features

  • True symmetric column design
  • “Double S” column design with single piece construction provides a channel for the bearings to travel in, maximizing the strength of the column and surface contact area of the bearing
  • Single point lock release which releases the locks at the same time
  • Two full stroke cylinders, one in each column
  • Arm restraints on each arm engage when the vehicle is lifted
  • Third party certified

Warranty

One (1) year for parts and labor.  Additional one-year parts warranty if installed by a Rotary Authorized Installer (RAI)

Product Specifications

  • Rise: 80-1/4" (2038mm)
  • Height Overall: 11' 8-1/2" (3569mm)
  • Overall Width: 11' 5-1/2" (3493mm)
  • Drive-thru Clearance: 102-1/2" (2603mm)
  • Floor to Overhead Switch: 11' 2-3/4" (3423mm)
  • Reach (front arm min.): 27-1/2" (699mm)
  • Reach (front arm max.): 59" (1499mm)
  • Rear (rear arm min.): 27-1/2" (699mm)
  • Rear (rear arm max.): 59" (1499mm)
  • Minimum Adapter Height: 4-3/4" -7-1/4" (121mm - 184mm)
  • Low Step Height: 8-1/4" - 10-3/4" (210mm - 273mm)
  • High Step Height: 9-3/4" - 12-1/4" (248mm - 311mm)
  • Inside of Columns: 114-1/2" (2908mm)
  • Cylinder Height at Full Rise: 11' 10-3/4" (3626mm)
  • Lifting Capacity: 10,000 lbs. (4536 kg)
  • Motor / Voltage: 208V-230V, 2HP
  • Time of Full Rise: 45 seconds
  • Ceiling Height Required (Standard): 12' (3658mm)
  • Maximum Load per Arm: 2,500 lbs. (1134 kg)
  • Minimum Bay Size: 12' x 24' (3658mm x 7315mm)
